Transducer Garmin GT51M-TH
This through-hull transducer provides remarkably clear visuals of objects, structures, and fish located beneath your vessel. It is equipped with a traditional CHIRP sonar, as well as CHIRP DownVü and SideVü functions, all optimized for exceptional performance even at great depths and in challenging sea conditions.
The CHIRP DownVü and SideVü components each deliver 500 watts of power (totaling 1,500 watts) and operate at frequencies of 260 kHz and 455 kHz. The traditional CHIRP sonar supplies 600 watts of power with an average frequency range of 80-160 kHz. Additionally, it features a rapid response built-in temperature sensor and is designed for hull support angles of less than 25 degrees.
The GT51M-TH package includes a 12-pin transducer, a stainless steel wheel, a fairing block, bushings, an isolation plate, assembly parts, and installation guidelines. It is crucial to follow these instructions carefully to avoid any potential damage to your boat.
Specifications:
- Frequency: Medium band CHIRP (80-160 kHz); ClearVü/SideVü CHIRP 260 kHz (245-275 kHz) and 455 kHz (445-465 kHz)
- Power: Traditional CHIRP 600 W; ClearVü/SideVü 500 W
- Beam Width: Traditional: 24°-13°; ClearVü/SideVü: 2.0°x51° at 260 kHz and 1.4°x29° at 455 kHz
- Maximum Depth: Traditional: 1,800 ft; ClearVü: 1,000 ft; SideVü: 750 ft
- Cable Length: 5 ft plus a 30 ft extension cable
- Depth/Speed/Temperature: Depth and temperature
- Number of Pins: 12 pins
- Permitted Stern Mirror Angles: Up to 5° tilt
This transducer is an essential asset for any serious angler or navigator who seeks to enhance their marine experience with superior imaging and reliability. Invest in your boating adventures with this top-of-the-line sonar technology.
