Hydraulic Cylinder Ultraflex UC95-OBF/3
- Stock: En stock
UC95-OBF/3: Optimized Performance
The rotation speed of the locking wheel is consistent across both port and starboard sides.
Features adjustable 'boss' style connections for easy installation.
Includes a high-strength stainless steel connection bolt (ULTRABOLT).
Equipped with replaceable end caps for the cylinder.
Innovative Design (Patent Pending)
The split mounting rod with a pin for the cylinder optimizes installation and incorporates bushings to minimize friction with the engine tilt tube.
Applications
The UC95-OBF front mounting cylinder is ideal for outboard motors up to 175 hp and vessels that do not exceed 55 mph (48 knots). Not recommended for competitive purposes.
Specifications
- Volume: 95 cc (5.8 cu in)
- Output Force: 278 kg (613 lbs)
- Inner Diameter: 30 mm (1.18 in)
- Stroke: 186 mm (7.3 in)
- High Pressure Flexible Hose Connections: 3/8 in
- Bleed Connections: Quick connect DN5
Enhance your boating experience with the reliable and efficient UC95-OBF/3 mounting cylinder, designed to deliver optimal performance under challenging marine conditions.
