Hydraulic Cylinder Ultraflex UC128P-OBF/2
- Stock: Agotado
The UC128P-OBF/2 is a front-mounted cylinder designed to ensure balanced wheel rotations on both sides of your vessel.
Key Features:
- Adjustable boss-style connections for easy installation.
- Durable stainless steel connection bolt (ULTRABOLT).
- Replaceable end caps for maintenance convenience.
This cylinder is engineered for straightforward installation, making it compatible with most 2-stroke and 4-stroke outboard engines. It is recommended for use with the UP25, UP28, UP33, and UP39 command systems, and requires the standard UC128-OBF cylinder and a UC128P-OBF port cylinder for dual configurations.
Applications: Please note that it is not suitable for boats exceeding speeds of 55 mph (48 knots) or 65 mph (56 knots) in dual configurations, and it is not intended for racing use.
Specifications:
- Volume: 120 cc (7.3 cu.in)
- Output Force: 450 kg (992 lbs)
- Internal Diameter: 35 mm (1.37")
- Stroke: 185 mm (7.28")
- High-pressure flexible hose connections: 3/8"
- Purge Connections: DN5 quick connection
Enhance your boating experience with the reliability and efficiency of the UC128P-OBF/2 cylinder, a precise component designed for marine performance.
